A brief summary We offer professionals, the basic and advanced knowledge of SP3D by concentrating on: Equipment Piping Isometrics Structural […]

Smart Plant 3D (SP3D)

A brief summary

We offer professionals, the basic and advanced knowledge of SP3D by concentrating on:

  • Equipment

  • Piping

  • Isometrics

  • Structural

  • Drawing Creation

  • Pipe Support

sp3d-course

Syllabus

Introduction

  • Introduction

  • Starting a new SP3D Session Interface

  • Define Workspace

  • Refresh Workspace

  • Active Permission Group

  • View Manipulation

  • Clip Menu

  • Tools Menu

  • Task Menu

DESIGN MODULES

Equipment and Furnishing

  • Equipment and Furnishing Overview

  • Place Equipment Command

  • Place Equipment Component Command

  • Modelling of Horizontal Vessel

  • Modelling of Vertical Vessel

  • Modelling of Heat Exchanger

  • Modelling of Pumps

  • Place Designed Equipment Command

  • Place Designed Equipment Component Command

  • Place Shape Command

  • Place Nozzle Command

  • Replace Equipment Command

  • Move Command

  • Rotate Equipment Command

  • Mirror Command

  • Measure Command

Piping Module

  • Pipe routing- As per Piping layout and P&ID

  • Create a Pipeline System

  • Create a New Pipe Run

  • Editing Pipeline Properties

  • Routing of Lines

  • Working Plane Control Tool

  • Providing Slopes to the Lines

  • Inserting Components

  • Moving Pipe Features

  • How to provide Spec break

  • Deleting Features

  • Mirror Copy Command

  • Interactive Clash Checking

Isometric Module

  • Isometric Generation-As per pipe routings

  • Isometric Drawing by Query Manager

  • Setup of Filter and Package

  • Creating of Drawing

  • Export the drawing to AutoCAD

Structural Module

  • Structures-As per Equipment Layout & Piping Layout Grid

  • Grid Creation

  • Grid Modification

  • Grid Placement

  • Beams and Column
  • Create beams and Columns
  • Extend beams and Columns
  • Splitting & trimming of beams
  • Creating Bracings
  • Structural Commands( All Structural Commands are Covered)
  • Slabs
  • Creating Slabs
  • Slab modifications
  • ASL
  • Creation of platforms, Handrails
  • Creation of Ladders
  • Creation of Stairs

Draft Module

  • Final output of plant layout

  • Creating Volume Drawing and Assigning Properties

  • Defining the Volume in Space Management

  • Updating the Drawing

  • Export the drawing to AutoCAD

Full Syllabus Download

  • Introduction

  • Design Module

  • Equipment And Furnishing

  • Piping Module

  • Isometric Module

  • Structural Module

  • Draft Module
